Standard NPT Thread: Used in the U.S. for pipes, fittings, and cable connections, ensuring a secure fit.
Strain Relief Mechanism: Nut or compression system prevents cable pullout, reducing stress and damage.
Versatile Material Options: Available in plastic, metal, or liquid-tight variants for different environments.
Easy Installation: User-friendly design allows quick setup with a secure, stable grip.
Corrosion-Resistant & Durable: Smooth, polished surface enhances longevity and withstands harsh conditions.
Enhanced Safety Features: Prevents accidental disconnection and minimizes electrical hazards for reliable cable management.
| Material | Nickel-plated brass, PA (NYLON), UL 94 V-2 |
| Seal | EPDM (optional material NBR, Silicone Rubber, TPV) |
| O-Ring | EPDM (optional material, Silicone Rubber, TPV, FPM) |
| Working Temperature | -40℃ to 100℃ |
| Color | V0 or F1 can be offered upon request |
| Oerigo Part Code | Size | Cable Range mm | H mm | GL mm | Spanner Size mm | MOQ |
|---|---|---|---|---|---|---|
| OG-BNP-NPT-3808G | 3/8″ NPT | 4-8 | 21 | 15 | 17/19 | 100 Pcs |
| OG-BNP-NPT-3806G | 3/8" NPT | 2-6 | 21 | 15 | 17/19 | 100 Pcs |
| OG-BNP-NPT-1212G | 1/2" NPT | 6-12 | 24 | 13 | 22/24 | 100 Pcs |
| OG-BNP-NPT-1259G | 1/2" NPT | 5-9 | 24 | 13 | 22/24 | 100 Pcs |
| OG-BNP-NPT-3418G | 3/4 " NPT | 13-18 | 25 | 13 | 30 | 100 Pcs |
| OG-BNP-NPT-3416G | 3/4 " NPT | 9-16 | 25 | 13 | 30 | 100 Pcs |
| OG-BNP-NPT-1020G | 1 " NPT | 13-20 | 29 | 19 | 40 | 100 Pcs |
| OG-BNP-NPT-1025G | 1 " NPT | 18-25 | 29 | 19 | 40 | 100 Pcs |
| OG-BNP-NPT-11425G | 1/1/4 " NPT | 18-25 | 31 | 17 | 44 | 75 Pcs |
| OG-BNP-NPT-11420G | 1/1/4 " NPT | 13-20 | 31 | 17 | 44 | 75 Pcs |
| OG-BNP-NPT-11432G | 1/1/2 " NPT | 22-32 | 37 | 20 | 50 | 50 Pcs |
| OG-BNP-NPT-11426G | 1/1/2 " NPT | 20-26 | 37 | 20 | 50 | 50 Pcs |
| OG-BNP-NPT-2044G | 2 " NPT | 37-44 | 38 | 21 | 64 | 50 Pcs |
| OG-BNP-NPT-2035G | 2 " NPT | 29-35 | 38 | 21 | 64 | 50 Pcs |
